Description
The APS worktop template makes it easy to create flush joins in wood boards at 90° angles. The template is secured firmly using the integrated clamping mechanism, for precise results – even when making multiple routing passes in the same groove.
- Panel depths greater than 900 mm also possible using the extension profiles
- Robust routing template made from aluminum
- For corner and panel joints with fixed fence with panel depths of 600 and 650 mm or, if moved, up to 900 mm
- For groove cutters with 14 mm diameter and copying rings with 30 mm diameter, recommended for OF 2200 router
- Additionally with two routing templates that can be freely positioned for making recesses for conventional fittings on the underside of panels
Scope of Delivery
- Routing Worktop Template
- Profile MFS-VP 1000
Technical Data
| Product Name | Routing Worktop Template APS 900/2 |
|---|---|
| Dimensions | 1000 x 380 x 16 mm |
| Panel depth with corner joints, without adjustment | 600/650 mm |
| Panel depth with corner joints, with adjustment | 900 mm |
| Bolt length | 65/150 mm (for worktop connectors) |
Compatible Tools
- OF 1010 W Plunge Router Plus
- OF 1400 W Plunge Router
- OF 2200 W Plunge Router Plus
- Routing Worktop Template APS 900/2
