Description
Features
- Ideal for mobile use due to low weight
- Lateral depth stop adjustment
- Large table length
- Powerful universal motor for powerful lugging drive and even planing result
- Precise thickness adjustment for quick and exact planing
- Large supply and delivery tables support the conveyance of long materials; for ideal planing results
- Planing locking mechanism prevents unintentional adjustment of the chip removal setting and guarantees precise work results
- For single phase alternating current
Specifications:
|
| Dimensions L x W x H |
579 x 857 x 574 mm |
| Chip removal |
| – Thickness planing |
0 – 3 mm |
| Material |
| – Thickness table |
Cast aluminium / special steel aluminium |
| Thickness table L x W |
840 x 330 mm |
| Passage height/width |
152 mm/330 mm |
| Feed rate |
7,51 m/min |
| Diameter of blade shaft |
47 mm |
| Number of blades |
2 |
| Blade shaft speed |
9.800 /min |
| Mains voltage |
230/400 V |
| Rated input power |
1,8 kW |
| Fuse protection |
T 16 A |
| Weight |
35 kg |
| Includes: |
| 2 integrated HPHSS reversible planer blades |
| push stick |
| extraction nozzle |
